TK-RUTM30
TK-RUTM30
- Teltonika Industrial Router 5G
- Automatic failover between WAN, mobile, and Wi-Fi
- Wi-Fi connectivity 5 up to 300 Mbps
- Reliability with eSIM and a physical SIM card slot
- Advanced VPN: IPsec, OpenVPN and WireGuard
- Compact aluminum chassis with DIN rail mounting
The Teltonika RUTM30 is a 5G rugged, secure and multi-purpose industrial router, perfect for applications requiring advanced speed, redundant connectivity, remote management and resilience in industrial environments. Includes 5G Sub-6GHz connectivity (supporting 4G/3G), dual physical SIM and eSIM with auto-switching, and dual-band Wi-Fi 5 for high capacity. Its low power consumption, passive PoE compatibility and wide power range make it an efficient solution for critical IoT, video surveillance or automation deployments.
Enables centralized management via RMS for monitoring, updating and remote control, and supports multiple VPN protocols, ensuring private communications and data protection between connected networks or devices. Offers advanced firewall, VLAN, client isolation and enterprise authentication, maintaining integrity and security on all connections.
Specifications
| Brand | Teltonika |
| Device | Industrial 5G Router |
| Wi-Fi | Wi-Fi 6 802.11ac Dual Band 2.4GHz+ 5GHz [%VAR%] |
| LTE | 5G Sub-6Ghz SA/NSA 2.4/3.4Gbps DL (4x4 MIMO), 900/550 Mbps UL (2x2) |
| Ethernet | 2 Ethernet ports RJ45 10/100/1000Mbps (1 WAN + 1 LAN) |
| Antenna connectors | WiFi and LTE (antennas included) |
| CPU | Mediatek, Dual-core, 880 MHz, MIPS1004Kc |
| RAM | 256MB DDR3 |
| Flash | 16MB serial NOR flash, 256MB serial NAND flash |
| Operating System | RutOS (Based on OpenWRT) |
| Network Protocols | TDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, FTP, SMTP, SSL v3, TLS, ARP, VRRP, PPP, PPPoE, PPPoE, UPNP, SSH, DHCP, Telnet, SMPP, SNMP, MQTT, BGP, OSPF v2, RIP v1/v2, EIGRP, NHRP |
| VPN Protocols | OpenVPN, IPsec, GRE, PPTP, L2TP, Stunnel, DMVPN, SSTP, WireGuard, ZeroTier, Tinc, Tailscale |
| Monitoring and Management | WEB UI, CLI, SSH, SMS, TR-069, SNMP, JSON-RPC, MQTT, RMS, MODBUS |
| Cloud Solutions | RMS, FOTA, Telenor, Azure IoT Hub, Cloud of Things, Cumulocity, ThingWorx, AWS IoT Core |
| Services | DDNS, VRRP, Wake On Lan (WOL), WEB filter, UPNP, Network shares (Samba), Traffic Logging |
| Power | DC connector 4 Industrial pins 9~50V Power Supply Included Possibility to power through LAN1 port with Passive PoE (Cannot power with IEEE802.3af, 802.3at and 802.3bt standards, Mode B) 9 - 30 VDC |
| Material | Aluminium |
| Temp. operation | -40º C ~ +75º C |
| Operating humidity | 10 ~ 90 % (non-condensing) |
| Optional Mounting Kit (Not included) | Rail Mounting Kit, Compact Rail Mounting Kit, Surface Mounting Kit |
| Dimensions | 30 (Al) x 100 (W) × 93,70 (D) mm |
| Weight | 319 g |
| Inputs and Outputs | 1 x Digital Input, 0 - 6 V detected as low level, 8 - 50 V detected as high level 1 x Digital Output, Open Collector Input, Maximum Output 30 V, 300 mA |
| Dual SIM | Auto Switch in case of low signal / data limit / roaming / no network |
| Region | Europe, Middle East, Africa, Australia, APAC2, Brazil, and Malaysia |
In the box
- Industrial Router
- 2x Wi-Fi Antennas
- 4x LTE Antennas
- AC power supply 18W
- Ethernet Cable 1,5m
- User instructions
- 1x SIM Adapter
