TK-RUT271

TK-RUT271

Log in voor B2B prijs
  • Teltonika Router Redcap 5G Industrial
  • 2 Ethernet ports RJ45 Fast Ethernet
  • Redcap 5G to 223Mbps
  • 1x Digital Input/Output
  • Wi-Fi 802.11b/g/n 2.4GHz
  • Aluminum Housing

The Teltonika RUT271 is a compact industrial router ideal for applications requiring reliable and cost-effective connectivity in demanding environments. Thanks to its compatibility with 5G RedCap and 4G LTE, it is widely used in sectors such as industrial automation, enabling secure communication of sensors and controllers; in the remote monitoring of infrastructures such as solar plants, weather stations or water wells; and in the management of urban services such as video surveillance cameras, traffic lights and electric charging stations. It is also an effective solution for fleet tracking and logistics, as well as for establishing temporary networks for events, construction sites or emergency situations.

RMS (Remote Management System): This router enables remote management through the RMS platform, facilitating monitoring and control of connected devices from any location. This is especially useful for companies that need to manage multiple routers in different locations, as it provides a centralized interface for configuration, upgrades and device status monitoring.

VPN (Virtual Private Network): Supports multiple VPN protocols, enabling secure, private connections over the Internet. This is ideal for protecting sensitive information and ensuring that communications between different networks or devices are secure. With the ability to configure VPNs, users can access the network remotely without compromising security.


  • Router Redcap 5G Industrial
  • Redcap 5G 7 4G Cat4
  • 1 SIM Slot
  • 2 Ethernet ports RJ45 Fast Ethernet
  • Wi-Fi 802.11b/g/n 2.4GHz
  • 1 Digital Input/Output
  • 2x SMA for LTE antennas and 1x RP-SMA for Wi-Fi antenna
  • 128MB RAM and 580MHz CPU
  • Industrial 4 pin DC power connector
  • DC power 9 to 30V Power Supply Included
  • Status LEDs

Specifications

Brand Teltonika
Device Router Redcap 5G Industrial
Ethernet 2 Ethernet ports RJ45 10/100Mbps (1 WAN + 1 LAN)
CPU Mediatek MIPS 24Kc 580 MHz
RAM 128MB DDR2
Flash 16MB
Wi-Fi features 802.11b/g/n 2.4GHz (AP Mode and STA Mode)
Mobile Coverage 5G Sub-6Ghz SA 223 Mbps , 4G LTE Cat 4 - LTE 195 Mbps
Maximum Number of Wi-Fi Clients 50 (Depending on traffic generated)
Operating System RutOS (Based on OpenWRT)
Network Protocols TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, FTP, SMTP, SSLv3, TLS 1.3, ARP, PPP, PPPoE, DHCP, Telnet
VPN Protocols OpenVPN, IPsec, GRE, PPTP, L2TP, Stunnel, DMVPN, SSTP
Monitoring and Management WEB UI, CLI, SSH, SMS, TR-069, SNMP, JSON-RPC, MQTT, RMS
Cloud Solutions RMS, FOTA, Telenor, Azure IoT Hub, Cloud of Things, Cumulocity, ThingWorx
Services DDNS, VRRP, Wake On Lan (WOL), WEB filter, UPNP, Traffic Logging
Inputs and Outputs 1 x Digital Input, 0 - 5 V detected as low level, 8 - 30 V detected as high level
1 x Digital Output, Open Collector Input, Maximum Output 30 V, 300 mA
Power DC connector 4 Industrial pins 9~30V Power Supply Included
Material Aluminium
Temp. operation -40º C ~ +75º C
Operating humidity 10 ~ 90 % (non-condensing)
Optional Mounting Kit (Not included) Rail Mounting Kit, Compact Rail Mounting Kit, Surface Mounting Kit
Dimensions 25 (Al) x 83 (W) × 74 (D) mm
Weight 130 g

In the box

  • Router Redcap 5G Industrial
  • AC power supply 9W
  • Ethernet Cable 1,5m
  • User instructions
  • 2x LTE Antennas
  • 1x Wi-Fi Antenna
  • 1x SIM Adapter
