TK-RUT260-V2
TK-RUT260-V2
- Industrial Router 4G LTE Cat 6 up to 300 Mbps.
- Quectel mobile chipset for high stability.
- Built-in Wi-Fi connectivity 4 (802.11n).
- 2 Ethernet ports 10/100 Mbps (WAN/LAN).
- Ultra-compact design in an aluminum housing.
- Advanced support for VPN protocols and security.
The TK-RUT260-V2 is an industrial LTE Cat 4G cellular router that retains the standard model's ultra-compact design but incorporates a Quectel chipset to optimize reliability and performance in mobile connections. With download speeds of up to 300 Mbps and carrier aggregation technology, this device ensures smooth data transmission in critical automation, retail, and smart city applications where installation space is extremely limited.
Based on the RutOS operating system, it offers an industrial-grade security suite that includes an advanced firewall, DDoS attack prevention, and multiple VPN services such as OpenVPN and WireGuard. Its ruggedized hardware, housed in an aluminum chassis, withstands temperatures of up to 75 °C, featuring Wi-Fi for 50 simultaneous users and digital inputs/outputs for efficient monitoring of remote assets.
Remote Management (RMS): Compatible with Teltonika RMS for centralized and secure fleet management from anywhere. It enables real-time monitoring, remote access (RMS Connect), and bulk updates, reducing operating costs by eliminating the need for on-site visits.
- Router 4G LTE Cat 6 up to 300 Mbps DL.
- Wi-Fi 4 (802.11n) up to 50 simultaneous users.
- 2 Ethernet ports 10/100 (1 WAN, 1 LAN).
- 1 Mini SIM slot (2FF) with optional eSIM.
- RutOS Operating System based on OpenWrt.
- Mediatek processor 580 MHz MIPS 24KEC.
- RAM: 128 MB and Flash: 16 MB.
- 1 digital input and 1 digital output via DC connector.
- Industrial power supply range: 9 at 30 VDC.
- Ruggedized aluminum housing with a rating of IP30.
Specifications
| Brand | Teltonika |
| Type of equipment | Industrial Cellular Router (Quectel Chipset) |
| Mobile module | 4G LTE Cat 6 (300 Mbps DL / 50 Mbps UL), 3G |
| Mobile Phone Chipset | Quectel (Stability Optimization) |
| Standard 3GPP | Release 12 |
| SIM slot | 1 x Mini SIM (2FF), 1.8 V/3 V |
| eSIM | Optional (consumer type), up to 7 profiles |
| WiFi | 802.11b/g/n (Wi-Fi 4), AP and STA mode) |
| WiFi rate | Up to 150 Mbps; 50 concurrent users |
| Ethernet WAN | 1 x WAN port 10/100 Mbps, compliant with IEEE 802.3 |
| Ethernet LAN | 1 x LAN port 10/100 Mbps, compliant with IEEE 802.3 |
| RAM memory | 128 MB, DDR2 |
| Flash Storage | 16 MB, SPI Flash |
| Digital Input | 1 x Digital Input (0-6 V low, 8-30 V high) |
| Digital Output | 1 x Digital Output (Open collector, 30 V, 300 mA) |
| VPN | OpenVPN, IPsec, GRE, PPTP, L2TP, Stunnel, DMVPN, ZeroTier, WireGuard, Tinc |
| Network Protocols | TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP/S, SFTP, FTP, SMTP, SSL/TLS, ARP, VRRP, PPP, PPPoE, UPNP, SSH, DHCP, Telnet, SMPP, SNMP, MQTT, WOL, VXLAN |
| IIoT Protocols | Modbus TCP (Server/Client), OPC UA (Client/Server), DNP3 (Station/Outstation), DLMS |
| Security | SPI Firewall, DDoS Prevention, VLAN, Web Filter, 802.1x |
| Management | Web UI, CLI, SSH, SMS, TR-069, MQTT, SNMP, RMS |
| Power | 9 - 30 VDC (industrial connector with 4 pins) |
| Passive PoE | Supported via the LAN1 port (Mode B, 9-30 VDC) |
| Energy Consumption | Rest: < 2 W; Maximum: < 6.5 W |
| Housing Material | Anodized aluminum, plastic panels |
| IP protection | IP30 |
| Temp. Job | -40 °C to +75 °C |
| Humidity at Work | 10% to 90% (no condensation) |
| Dimensions | 83 x 25 x 74 mm |
| Weight | 130 g |
In the box
- 1x Router RUT260-V2.
- 1x Power supply for 9W.
- 2x Mobile antennas (swivel, SMA male).
- Wi-Fi antenna (swivel, RP-SMA male).
- 1x Cable Ethernet (1.5 m).
- 1x SIM adapter kit and Quick Start Guide.
