TK-PR1KCS28
Ga direct naar de productinformatie
TK-PR1KCS28
- Teltonika Antenna
- LTE/Wi-Fi/GNSS Combo
- Vehicle roof mounting
- SMA connectors
- Outdoor certificate IP67
- Cables RG174 3 meters long
- Teltonika
- LTE GNSS Wi-Fi Combo Antenna for vehicle rooftop
- LTE Frequency 617-960/1710-2690 MHz Connector 1x SMA Male
- GNSS antenna 1575-1610 MHz 1x SMA Male Connector
- Wi-Fi antenna 2350-2500 MHz Connector 1x RP SMA Male
- Exterior Certification IP67
- 3x Cables RG174 3 meter long
Specifications
| Mounting | Ceiling mounting (screwed) |
| LTE Antennas | Frequency Range: 617-960/1710-2690 MHz Polarization: Linear Gain: 3.5dBi V.S.W.R < 1.5 Impedance: 50 ohms 1x SMA Male connectors |
| Wi-Fi antennas | Frequency: 2350-2500 MHz Polarization: Linear Gain: 2.5 dBi V.S.W.R < 1.5 Impedance: 50 ohms 1x RP-SMA Male Connectors |
| GNSS Antenna | Frequency: 1575-1610 MHz Polarization: RHCP Impedance: 50 ohms LNA gain: 28±2 dB Noise LNA: < 1.5 dB 2.7-5 ±0.5Vdc Voltage Current consumption < 15mA LNA V.S.W.R < 1.5 1x SMA Male connector |
| Cables | 3x RG174, 3 meters |
| Dimensions | 110x55mm |
| Weight | < 225g |
