TK-PR1KCO28
Ga direct naar de productinformatie
TK-PR1KCO28
- Teltonika Antenna
- LTE/Wi-Fi/GNSS Combo
- Vehicle roof mounting
- SMA connectors
- Outdoor certificate IP65
- Cables RG174 3 meters long
- Teltonika
- LTE GNSS Wi-Fi Combo Antenna for vehicle rooftop
- LTE Frequency 698-960/1710-2690 MHz Connector 2x SMA Male
- GNSS antenna 1575.42-1610 MHz 1x SMA Male Connector
- Wi-Fi antenna 2400-2483.5/4900-5825 MHz Connector 2x RP SMA Male
- Exterior Certification IP65
- 5x Cables RG174 3 meter long
Specifications
| Mounting | Ceiling mounting (screwed) |
| LTE Antennas | Frequency Range: 698-960/1710-2690 MHz Polarization: Linear Gain: 3dBi V.S.W.R < 3.0 Impedance: 50 ohms 2x SMA Male connectors |
| Wi-Fi antennas | Frequency: 2400-2483.5/4900-5825 MHz Polarization: Linear Gain: 2dBi V.S.W.R < 1.5 Impedance: 50 ohms 2x RP-SMA Male Connectors |
| GNSS Antenna | Frequency: 1575.42-1610 MHz Polarization: RHCP Impedance: 50 ohms LNA gain: 28±2 dB Noise LNA: < 1.5 dB Voltage 3-5 VDC Current consumption < 15mA LNA V.S.W.R < 2.0 1x SMA Male connector |
| Cables | 5x RG174, 3 meters |
| Dimensions | 110x55mm |
| Weight | < 550g |
