SF-VIMOD-DISP-MF
Ga direct naar de productinformatie
SF-VIMOD-DISP-MF
- Extension module
- IPS touch screen 4" | Keyboard and directory
- Opening with MF card and PIN
- Storing 500 contacts
- Suitable for outdoor use IP65 | IK08
- Modular
- Safire
- Video-intercom extension module
- IPS LCD color touch screen 4"
- Card reader
- Numeric keypad
- Contact directory
- MF card opening 13.56 MHz and access codes
- Calling an apartment number and contacts
- Storage of up to 500 contacts
- Customizable screensaver
- Suitable for exterior IP65
- Anti-vandal IK08
- Compatible with Safire IP video intercom module
Specifications
| Brand | Safire |
| Model | SF-VIMOD-DISP-MF |
| Screen | 4" IPS color LCD touch screen |
| Functions | RFID card reader Numeric keypad for apartment calls and access codes Contact directory |
| Access methods | MF card (13.56 MHz) and PIN |
| Storage | Up to 500 different contacts/apartments |
| Inputs/outputs | Input: CVBS video Output: audio |
| Modular | Compatible with Safire extension modules |
| Remote access | Web browser on Safire modular board |
| Power | 4 wire communication between modules |
| Degree of protection | Suitable for exterior IP65 Anti-vandal IK08 |
| Temp. operating | -20 ºC ~ +60 ºC |
| Dimensions | 98 (H) x 100 (W) x 34.2 (D) mm |
In the box
- Safire modular video intercom keypad
- Mounting material
- User instructions
