SF-POE-EXT0302-60W
Ga direct naar de productinformatie
SF-POE-EXT0302-60W
- Safire Indoor PoE Extender
- Extends PoE power range up to 650 meters
- 2 PoE Out + 1 Uplink RJ45 PoE In ports
- Hi-PoE IEEE 802.3 af/at/bt
- Maximum output power 60 W
- Speed 10/100Mbps
- Safire
- Indoor PoE Extender Switch
- Allows to extend the range of POE power to 3 RJ45 ports 100 Mbps (1 uplink + 2 POE of 30 and 60W )- IEEE 802.3 af/at/bt
- Transmission distance up to 130 meters using UTP cable of 5 categories
- Output power up to 60W
- Requires Power over Ethernet (PoE)
Specifications
| Brand | Safire |
| Interface | 1 PoE Out Hi-PoE port up to 60W 1 PoE Out PoE+ port up to 30W 1 Uplink PoE Port In 60W |
| Port speed | 3x 10/100 Mbps |
| Power supply | 30 y 60W |
| PoE features | According to IEEE 802.3at / IEEE 802.3af / IEEE 802.3bt PoE Standard |
| Power | Requires PoE power and the use of a PoE injector or switch that complies with the 802.3bt standard is recommended |
| Dimensions | 102 x 34 x 20.5 mm |
| Range | Each extender allows the distance to be increased by up to 130m If the extender is powered with PoE+ (30W) up to 3 cascaded extenders can be used. If the extender is powered with Hi-PoE (60W) up to 5 cascaded extenders can be used. |
In the box
- Indoor POE extender Switch
- User instructions
