SF-NVR3104-4P-B1
Ga direct naar de productinformatie
SF-NVR3104-4P-B1
- Safire Smart
- NVR recorder for IP cameras - B1 range
- 4 CH video PoE 40W / Compression H.265
- Up to 8Mpx resolution / 40Mbps Bandwidth
- Outputs 4K HDMI & VGA
- Supports VCA events from IP cameras / POS function
- Safire Smart
- B1
- NVR for IP cameras
- 4 CH
- 40 Mbps bandwidth supported
- Maximum resolution 8 Megapixel (3840x2160)
- Compression H.265/H.264
- Outputs 4K HDMI & VGA
- POS Function
- IP Dual Stream Access
- Mouse
- RCA Audio
- Space for 1 HDD
- 4 PoE ports IEEE802.3af
- WEB, CMS and Smartphone interface
- ONVIF Compatible
Specifications
| Brand | Safire Smart |
| Range | B1 |
| Inputs for IP cameras | 4CH IP / LAN Ports up to 4CH PoE |
| IP compatible cameras | Safire Smart (native protocol), ONVIF |
| Power over Ethernet | 4 IEEE 802.3af (Max. 40W) 10/100/1000M |
| Bidirectional audio | 1 input / 1 RCA output |
| Video outputs | 1 HDMI 4K, 1 VGA |
| Main Stream recording | 8MP/6MP/5MP/4MP/3MP/1080P/1280×1024/960P/720P/ 960H/D1/CIF |
| Decoding capacity | 1CH 8Mpx 4CH 1080P |
| Video compression format | H.265 / H.264 |
| Audio Compression | G.711(U/A) |
| Total bandwidth | 40 Mbps downstream / 40 Mbps upstream |
| Display resolution | HDMI: 3840x2160, 2560x1440, 1920x1080, 1280x1024, 1280x720, 1024x768 VGA: 1920x1080, 1280x1024, 1024x768 |
| Alarms | Does not have |
| POS Function | Yes |
| Recording method | Manual, programmed, motion detection, smart events, alarm input, POS |
| Simultaneous multifunction | Pentaplex: Live, Recording, Playback, Backup and Remote Access |
| External Backup | USB memory stick / USB HDD / USB CD-RW / USB DVR-RW / |
| Internal memory | 1x 3.5" HDD SATA3.0 up to 8 TB (not included) |
| Communication | 2 x USB 2.0 / 1 x RJ45 10/100/1000M (Ethernet) |
| Remote access | Web Browser, Safire Smartphone App and PC Software Safire Smart VMS |
| Power | DC 48V / 1.25A, < 10W (Without hard disk) |
| Operating temperature | -10ºC ~50ºC, Humidity 90% |
| Dimensions / Weight | 45 (H) x 300 (W) x 249 (D) mm / 0.9 Kg |
In the box
- Safire Smart NVR Recorder
- Mouse
- Ethernet Cable
- Power supply 48V DC
- Quick Guide
