SF-IPD540ZA-8I1
Ga direct naar de productinformatie
SF-IPD540ZA-8I1
- Safire Smart
- Dome IP camera range I1 Advanced AI
- Resolution 8 Megapixel (3840x2160)
- Motorized Lens 2.8-12 mm | Microphone | IR 50m
- Advanced AI:Human, vehicle and vehicle 2 wheels
- IP67 Rating | PoE (IEEE802.3af) |Alarm
- Safire Smart
- I1
- IP Dome Camera
- 1/2.8" Progressive Scan CMOS
- 8 Megapixel (3840x2160)
- 2.8-12 mm Motorised Lens
- 0 Lux
- IR Range 50 m
- Compression H.265+ / H.264+
- WDR
- 3DNR
- Integrated microphone
- Audio
- Alarm input / output
- MicroSD card up to 256GB
- TrueSense: Classification of human and vehicle
- WEB, CMS, Smartphone and NVR interface
- ONVIF Compatible
- PoE (IEEE802.3af)
- 3 Axis
- Weatherproof IP67
- Vandal proof IK10
Specifications
| Brand | Safire Smart |
| Range | I1 |
| Image sensor | 1/2.8" Progressive Scan CMOS |
| Maximum resolution | 8 Megapixel (3840x2160) |
| Minimum illumination | Colour: 0.02 Lux @(F1.6, AGC ON), 0 Lux with IR |
| IR range | 50 m |
| Day/Night | Removable mechanical ICR filter |
| Electronic Shutter | 1/2~1/100.000 s |
| Main Stream rate | 20 FPS (8Mpx) 25 FPS (6Mpx, 5Mpx, 4Mpx, 2K, 3Mpx, 1080P, 720P) |
| Extra Stream rate | 25 FPS (720P, D1, 480x240) |
| Third Stream Rate | 25 FPS (720P, D1, CIF, 480x240) |
| Compression | H.265+ / H.265 / H.264+ / H.264 |
| Bitrate | 64 Kbps ~ 12 Mbps |
| Lens | Motorised 2.8-12 mm |
| Field Of View (FOV) | H: 99-34°, V: 53-18°, D: 115-36° |
| Range performance | W: 86 m (D), 34 m (O), 17 m (R), 9 m (I) T: 273 m (D), 109 m (O), 55 m (R), 27 m (I) |
| Image improvements | WDR (120dB), BLC, HLC, 3D-DNR, AWB, ROI, Mirror Function, Privacy Mask, ROI |
| Motion Detection | Yes |
| Smart Features | Advanced artificial intelligence based on human, vehicle and two-wheeled vehicle classification on: Area Intrusion, Line Crossing, Entry Region, Exit Region Other smart events: dropped object, removed object, Video exceptions (change of scene, video loss, ...) |
| Audio | Built-in microphone / 1 Input |
| Alarms | 1 Input / 1 Relay |
| Audio Compression | G711A / U |
| Network interface | Ethernet 10 / 100M BaseT |
| Internal memory | MicroSD card up to 256GB |
| Remote access | Web Browser, Smartphone App Safire Smart, PC Software Safire Smart VMS |
| Interoperability | ONVIF |
| 3 Axis | Yes |
| Power | DC 12 V / 666 mA / 8 W max. / IEEE802.3af PoE |
| Degree of protection | Weatherproof IP67, Anti-vandal IK10 |
| Material | Metallic |
| Temp. operation | -30º C ~ +60º C |
| Dimensions | 141 (Ø) x 100.2(Al) mm |
| Weight | 910 g |
In the box
- Safire Smart I1 IP Dome Camera
- Installation material
- Installation quick guide
