SF-AC107
- Standalone access control
- Access by EM card
- Relay output and push button
- Wiegand 26
- Time control : Anti-passback
- Valid for interior
A stand-alone access control device consists of a combination of a controller and a reader in a single unit: is able to identify users, decide whether or not they have permission to access the installation and operate the electronic lock through its relay.
This equipment allows identification through cards or key fobs with RFID EM technology of 125 kHz.
Advanced configurable functions: anti-pass-back technology (does not allow a person to pass through if he/she is already inside).
The configuration of users, credentials, as well as special functions, relay opening times or reader reading time, can be configured locally from the equipment itself.
- Safire
- Standalone access control
- Access by EM card
- Plastic housing
- LED indicator
- Wiegand 26
- Integrated controller (push button and relay)
- Timed control of opening, closing and alarm
- Includes remote for programming
- Anti-passback
Specifications
| Brand | Safire |
| Model | SF-AC107 |
| Capacity | Up to 10.000 cards |
| Identification modes | Card |
| Proximity card | RFID EM 125 kHz |
| Inputs/outputs | NO/NC relay and push button |
| Communication | Wiegand 26 |
| Special functions | Anti-passback Operation as a stand-alone terminal or as a reader Monostable or bistable relay operation |
| Power | DC 12 V |
| Consumption in idle mode | ≤ 30 mA |
| Degree of protection | Indoor |
| Temp. operation | -45 ºC ~ +60 ºC |
| Dimensions | 56 (W) x 115 (H) x 22 (D) mm |
| Weight | 400 g |
In the box
- Safire stand-alone access control reader
- Remote configuration control
- Installation material
- User instructions
