RG-OM-GE-SFP-10KM-SM1490
Ga direct naar de productinformatie
RG-OM-GE-SFP-10KM-SM1490
- Reyee e-Lighten Transceiver Module
- SFP Splitting PON
- SC Connector
- Tx 1480 nm a 1500 nm / Rx 1290 nm a 1330 nm
- Maximum distance 10 km
- Speed 1Gb/s
- Reyee
- E-Lighten transceiver module
- Transmission wavelength Transmission 1480/1500 nm
- Wavelength Reception 1290/1330 nm
- SC Connector
- Maximum distance 10 km
- 1Gb/s
Specifications
| Wavelength | Tx 1480 nm to 1500 nm Rx 1290 nm to 1330 nm |
| Fiber type | Splitting PON |
| Connector type | SC |
| Maximum distance | 10 km |
| Data Link | Up to 1Gb/s |
| Transmission power | Transmission from 3 to 7 dBm Receiving -32 at -12 dBm |
| Sensitivity | -32 dBm |
| Ethernet | Not supported |
| Power consumption | 1.5 W max |
| Operating temperature | 0° C ~ 70° C |
| Voltage | 3.14 V - 3.46 V |
| Weight | 0,035 kg |
In the box
- PON transceiver
