RG-NIS2100-4GT2SFP-HP
Ga direct naar de productinformatie
RG-NIS2100-4GT2SFP-HP
- Reyee Industrial Switch PoE Cloud Layer 2
- 4 Gigabit ports + RJ45 Gigabit SFP ports
- 4 PoE+ Ports 30W + 1 Hi-PoE Ports 90W
- Extended PoE (ports 3~4) / Port Isolation
- VLAN/ERPS/loop prevention/Watchdog/DHCP Snooping
- DIN rail mount
- Reyee
- Industrial Managed PoE Layer PoE Switch 2
- 4 ports RJ45 10/100/1000 Mbps + 2 Gigabit SFP Ports
- DIN rail mount
- 4 PoE/PoE+ ports (1~4) 1 PoE++ port (1) port)
- Extended PoE (3~4) ports)
- PoE power supply up to 180W total for all ports
- Compatible with PoE IEEE802.3af/at/bt
- Dual input for two power supplies
Specifications
| Interface | 4 ports RJ45 10/100/1000 Mbps + 2 SFP Ports |
| Port speed | 4 x 10/100/1000 Mbps - 2 x SFP Gigabit |
| PoE | Port 1 802.3bt 1~4 802.3af/at Ports |
| Power supply | Up to 180W PoE on all ports. Up to 90 W port 1 Up to 30 W port (1~4) If the device is powered from 46vDC to 57vDC, it can power up to IEEE 802.3af. If the device is powered from 50vDC to 57vDC, it can power up to IEEE 802.3at. If the device is powered from 52vDC to 57vDC, it can power up to 802.3bt IEEE (Type2). |
| PoE features | According to IEEE standard 802.3at PoE+ / IEEE 802.3af PoE / IEEE 802.3bt (Type2)PoE++ |
| VLAN | Up to 4094 Port-based Vlan |
| Redundancy control | ERPS (only available on its SFP ports) |
| Network Protocols and Technologies | DHCP Snooping Jumbo Frame 10000 Loop Prevention Flow control Storm control (unicast,broadcast,multicast) SPAN |
| Management Protocols | Web/Cloud/APP |
| Installation | DIN rail and/or wall |
| Power | Power supply not included 46-57VDC / 4,2A Reference is recommended: - RG-NIS-PA120-54 (will offer lower Total PoE Power) - RG-NIS-PA240-54 |
| Protections | 6KV against voltage spikes Input power protection 4KV/2KV [%VAR%] IP40 against dust EMC Level 4 |
| Operating temperature | -40ºC~65ºC In enclosed space -40ºC~75ºC With airflow |
| Recommended Industrial SFP Modules | RG-NIS-GE-SFP-10KM-SM1310 RG-NIS-GE-SFP-20KM-SM1310-BIDI RG-NIS-GE-SFP-20KM-SM1550-BIDI RG-NIS-GE-SFP-550M-MM850 |
| Dimenyesons | 500 x 430 x 195mm |
| Weight | 1,08 Kg (With packaging) |
| Easy switch | si |
In the box
- Switch
- User instructions
- Wall fixing brackets
