RG-NBS5200-24GT4XS-P
Ga direct naar de productinformatie
RG-NBS5200-24GT4XS-P
- Reyee Switch PoE Cloud Cloud Layer 3
- 24 PoE ports RJ45 Gigabit + 4 SFP+ 10Gb
- 30W per port 802.3af/at / Maximum 370W
- Static LAG/DHCP Snoop/IGMP Snoop/Port Mirror
- VLAN/Port Isolation/STP/RSTP/ACL/QoS/802.1X
- DHCP server/Static routes/RIP/OSPF/SNMP
- Reyee
- Manageable Desktop Switch Layer 3
- 24 ports RJ45 10/100/1000 Mbps + 4 SFP+ ports 10Gbps
- 24 PoE/PoE+ ports (ports 1~24)
- Supports PoE power supply up up 370W in total for all ports
- Compatible with PoE IEEE802.3af/at
Specifications
| Interface | 24 ports RJ45 10/100/1000 Mbps + 4 SFP+ Ports |
| Port speed | 24x 10/100/1000 Mbps - 4 x SFP+ 10 Gigabit |
| PoE features | 1~24 802.3af/at Ports Up to 30 W per (370W port for the entire device) According to norm IEEE 802.3at PoE+ / IEEE 802.3af PoE |
| VLAN | Up to 4096 Voice VLAN |
| Network Protocols and Technologies | LLDP/LLDP-MED IGMP Snooping v1/v2 CPU Protect Policy, Energy Efficient Ethernet ACL Jumbo Frame 9216 Static LAG LACP 802.1X |
| Protocols L3 | RIP OSPF Static Routing |
| Redundancy control | Spanning Tree (STP, RTSP) |
| Management Protocols | Web/Cloud/APP/SNMP |
| Power | AC 100 V - 240 V |
| Operating temperature | 0° C - 50° C |
| Dimensions | 357,6 (D) x 43.6 (H) x 440 (W) mm |
| Weight | 4,5 Kg (with packaging) |
In the box
- Manageable PoE Switch L3
- AC power cable
- User instructions
- Rack Mounting Brackets
