RG-ES126FGS-LP
Ga direct naar de productinformatie
RG-ES126FGS-LP
- Reyee Switch PoE - Rack mountable
- 24 Ports RJ45 + 1 Uplink RJ45 + 1 SFP Combo
- 24 Ports 10/100Mbps + 2 Ports 10/100/1000Mbp
- 24 PoE+ Ports 802.3af/at | Total Power 180W
- Port Isolation / Flow Control
- Plug and Play
- Reyee
- Unmanageable desktop switch
- 24 Ports RJ45 10/100Mbps
- 1 Gigabit Uplink port RJ45
- 1 Combo SFP Port
- 24 PoE+ Ports 802.3af/at
- Total PoE power 180W
- Metal housing
- Self-negotiating speed
- Fan with speed control
- Port Isolation
- Poe Extended
- Poe Watchdog -Energy saving technology
- Visible in Ruijie Cloud if there is at least one managed switch in the installation
- Plug and Play
Specifications
| Brand | Reyee |
| Interface | 24 Ports RJ45 10/100Mbps 1 Port RJ45 10/100/1000Mbps 1 Port SFP/RJ45 Combo (either the SFP port or the RJ45 port can be used, but not both at the same time) |
| PoE characteristics | 24 802.3af/at PoE+ Ports Up to 30W per port Total PoE power of 180W |
| Functions | Port Isolation, Poe Watchdog, Poe Extended Poe |
| Management | Unmanageable, but visible from Ruijie cloud if there is at least one manageable sw in the installation |
| Bandwidth | 8,8Gbps |
| Packet Forwarding Rate | 6,55Mbps |
| MAC Table | 8K |
| Supported Technologies | Auto-Negotiation / Auto MDI/MDIX mode |
| Power | 100V to 240V AC 3,5A |
| Maximum Consumption | < 180W |
| Operating temperature | 0º C ~ 45º C |
| Dimensions / Weight | 440 x 214,9 x 44 mm |
| Weight | 3,2 Kg |
In the box
- Switch
- Power supply cable
- User instructions
- Rack Anchor Kit
