RG-AP680P-L

RG-AP680P-L

Log in voor B2B prijs
  • Ruijie
  • Omnidirectional Wi-Fi AP 6
  • Suitable for outdoor use IP68
  • Supports 802.11a/b/g/n/ac/ax
  • Transmission speed up to 6000 Mbps
  • Antenna 4x4 MIMO / 160MHz
  • Ruijie
  • Wi-Fi 6 802.11AX dual-band omnidirectional 2.4 and 5 GHz Wi-Fi access point
  • Compatible with 802.11a/b/g/n/ac/ax Wave 1/Wave 2
  • Allows connections up to 6000 Mbps
  • MU-MIMO technology with 3 and 3 dBi antennas
  • MultiSSID -Bluetooth 5.1
  • Temperature range from -40 to 65 ºC
  • Powered by PoE 802.3af
  • IP68

Specifications

Brand Ruijie
Wireless standard Wi-Fi 6 802.11ax
Wi-Fi performance Up to 6000 Mbps
Radio1: 2.4GHz - 1147 Mbps
Radio2: 5GHz - 4804 Mbps
Frequencies 2.4 y 5GHz
Integrated antenna 4x4 Omnidirectional MIMO internal antennas
2.4GHz -> 3dBi
5GHZ -> 3dBi
Bluetooth Integrated Omnidirectional Antenna
Bluetooth 5.1
2dBi
10 dBm
Operating modes FIT: Adopted by Centralized AP Controller WS
FAT: Standalone mode - Local Web Access
Cloud: Managed through Ruijie Cloud
Security WPA / WPA2 (AES) / WPA-PSK / WPA3
Management Web/Cloud/APP/Console
Interface 1 Base-T Port 10/100/1000/2500/5000 Mbps PoE In
1 SFP+ Base-X Port 1000/2500/10000Mbps - Connects the AP at a distance of up to 20Km with single-mode fiber
1 Base-T Port 10/100/1000 PoE Out 48 V/12.95 W
1 Console Port RJ45
Concurrent Clients Maximum Software: 1024
Recommended: 64
Technologies Hidden SSID
Band Steering
Load balancing based on number of users or traffic
Bandwidth Control
PPSK authentication (Proprietary) and 802.1X
Rogue AP Detection
Isolation between Wi-Fi clients
CPU Protection Policy (CPP)
Network Baseline Protection Policy (NFPP)
Multicast to Unicast Conversion
SNMP V1, V2c, V3
Compatible Hardware Controller Series Controllers RG-WS6000
Exterior Certification IP68
Power PoE IEE802.3bt 40w (optimum functionality)
PoE IEE802.3at 25w (LAN port 2 cannot power devices)
PoE IEE802.3af 12,95w (Only GPS and Bluetooth radios will be operational)
Power consumption max 40w (10w in repso)
Operating temperature -40 °C ~ 65 °C
Dimensions 300 x 300 x 94 (without anchors)
Weight 3,3Kg

In the box

  • Access Point
  • Installation guide
  • Mounting Anchors
