QL-WR310

• Queclink Router 5G SA/NSA 3GPP Rel-16
• Superior resilience with Dual SIM auto-switch
• WiFi 6 MU-MIMO dual band hasta 2475 Mbps
• VPN secure (IPsec/OpenVPN) and Firewall NAT
• 4 puertos Gigabit (1 WAN, 3 LAN)
• Industrial ports RS232 and RS485

The WR310 is a top-tier solution for industrial connectivity, integrating cutting-edge 5G technology for ultra-fast and reliable data transfers. With its Dual SIM functionality, it ensures uninterrupted communication and network redundancy in the event of signal failures or network outages, while its rugged aluminum housing makes it ideal for deployments in challenging environments such as smart industry, edge computing, and energy management.

Technically, this router is powered by a dual-core 64-bit ARM CPU and runs on the OpenWrt operating system, which allows for advanced network customization and enhanced security. The device features RS232 and RS485 serial interfaces for industrial telemetry, high-precision GNSS positioning, and a wide operating voltage range of (8-32V DC with reverse polarity protection, ensuring complete operational stability in mobile, automotive, and mission-critical applications.

• Queclink
• 5G NR SA/NSA - Max 2.1Gbps (DL) / Max 900Mbps (UL)
• Global modem 5G/4G/3G
• 4 x Gigabit ethernet ports (1 x WAN + 3 x LAN)
• Various interfaces: 1 x RS232, 1 x RS485, 1 x DI, 1 x DO
• 2 x SIM, automatic changeover (Failover)
• Supports WIFI 6 802.11a/b/g/n/ac/ax
• Supports OpenVPN, Ipsec, GRE, PPTP, L2TP, Stunnel
• Supports Modbus (TCP/RTU), MQTT, HTTP and other IoT protocols
• Supports GNSS location (GPS/GLONASS/BeiDou/Galileo)
• RTC circuit with battery backup

Specifications

In the box

• 1x Router industrial WR310 FEU
• 1x Power supply (US Standard)
• 1x Ethernet Cable
• 1x Mounting bracket
• 1x Adhesive GNSS antenna
• 1x Mobile antenna kit 5G and WiFi
• 1x 5-pin connector
