MS-WS301-868M
- LoRaWAN magnetic contact
- Up to 15Km range with direct vision
- Installation on doors and windows
- Configuration via NFC and APP
- Degree of Protection IP20
- Long-lasting battery
- Milesight
- LoRaWan IoT magnetic contact
- Installation on doors and windows
- 5 years of battery (30 openings / day)
- Frequency 868MHz
- Communication range up to 15Km with direct view
- Easy configuration via NFC and smartphone APP
Specifications
| Frequency Band | 868 MHz |
| Sensitivity | -137dBm@300bps |
| Power Output | 16dBm Max. |
| Protocol | OTAA/ABP Class A |
| Scope of communication | Up to 15Km range with direct vision |
| Detection distance | 10 - 15 mm |
| Alarm | Open / closed status, tamper |
| Configuration | NFC via smartphone APP |
| Installation | Doors & Windows |
| Reliability | WAN failover |
| Power | 1x Battery 1650 mAh ER14335 Li-SOCI2 |
| Battery Life | 5 years (30 openings/day) |
| Operating temperature | -20ºC to 60ºC (Relative humidity <90%) |
| Grado de Protección | IP20 |
| Dimensiones | Sensor: 18.5 (Fo) x 50.5 (Al) x 31 (An) mm Imán: 1.3 (Fo) x 30 (Al) x 10 (An) mm |
| Material | Policarbonato anti-llama |
| Color | Blanco |
| Certificados | CE, FCC, RoHS |
In the box
- Contacto magnético
- Manual de instrucciones
- Material de montaje
