MS-VS133-P
Ga direct naar de productinformatie
MS-VS133-P
- Binocular AI People Counting Sensor
- Detection area: up to 3.5m
- Anonymous 100% detection
- Multiple advanced functions
- Multi-device reading connectionS
- Ethernet Port RJ45
- Milesight
- People counting sensor
- Detection based on Deep Learning and binocular vision
- Anonymous 100% detection (GDPR compliant)
- Detection area: up to 3.5m
- Recognition rate up to 99.8%
- Multiple advanced functions
- Bi-directional counting, differentiation of children/adults, by gender, groups, staff detection, shopping cart fill level detection, heat mapping
- PoE+
- Simple configuration
Specifications
| Brand | Milesight |
| Sensor | 2 x 4MP (2688x1520) |
| Installation height | ≤ 3.5 m |
| Field of view | 98° horizontally, 80° vertically |
| Detection area | 0.5m to 3.5m. |
| Reliability | Up to 99.8% |
| Advanced features | Bi-directional counting, differentiation of children/adults, by gender, groups, staff detection, shopping cart fill level detection, heat mapping |
| Configuration | Through web server |
| Led indicator | RGB |
| Alarm | 1 Input / 1 Output |
| Ethernet port | 1 × RJ45 10/100 Mbps (PoE PD) |
| Supported protocols | HTTP(s), MQTT(s), NTP, 802.1x, SSH, LLDP, BACnet/IP |
| Power | 802.3at PoE |
| Consumption | Typical 9.4 W, max 23.8 |
| Operating temperature | -20°C ~ 50°C |
| Relative humidity | 0% ~ 95% (no condensation) |
| Dimensions | 180mm. x 72mm. x 26mm. |
| Weight | 226 g |
| Colour | White |
| Material | Aluminium alloy |
| Certificates | CE, FCC, RoHS, GDPR |
In the box
- Binocular AI People Counting Sensor
- Instructions Manual
- Mounting material
