MS-UC100-868M
Ga direct naar de productinformatie
MS-UC100-868M
- LoRaWAN IoT Controller
- Up to 15Km range with direct vision
- Configuration via NFC and APP
- Up to 16 Modbus RTU devices
- Indoor installation
- Milesight
- LoRaWan IoT Controller
- Modbus RS485 to LoRaWan converter
- It can read up to 16 Modbus RTU devices
- Power supply via terminal block or USB-C
- Frequency 868MHz
- Communication range up to 15Km with direct view
- Easy configuration via NFC and smartphone APP
- Indoor installation IP30
Specifications
| Technology | LoRaWAN® |
| Frequency band | 868 MHz |
| Power Output | 16dBm Max. |
| Sensitivity | -137 dBm @300bps |
| Mode | OTAA/ABP Class C |
| Type of interface | 1x RS485 3.5 mm Terminal Block |
| Terminal resistance | 1 x 120 Ω Resister Switch |
| Baud rate | 1200~115200 bps: Transparent (RS232), Modbus RTU (RS485) |
| Protocol | Modbus RTU (RS485), Passthrough |
| Power supply | 5-24 VDC 5 VDC Type-C |
| Operating temperature | -20ºC ~ 60ºC |
| Environmental protection | IP30 |
| Dimensions | 70 x 45 x 13 mm |
In the box
- IoT Controller
- Connectors
- Installation accessories
- User instructions
