  • Milesight 4K Pro NVR 5000 series
  • Maximum resolution 4K | 8 channels
  • Bandwidth 160/160Mbps
  • Output 4K HDMI and VGA | 2 HDD
  • Supports LPR Milesight | ONVIF S/T cameras
  • NDAA Compliance
  • Milesight
  • NVR for IP cameras
  • 8 channels
  • Supported bandwidth 160/160Mbps
  • Maximum resolution 4K
  • Compression H.265+/H.265/H.264+/H.264
  • Audio
  • Alarms
  • VGA and HDMI 4K output
  • IP Dual Stream Access
  • Compatible with LPR Milesight cameras
  • Mouse
  • Space for 2 HDD up to 10TB
  • WEB, CMS/VMS and Smartphone interface
  • ONVIF S/T- NDAA compliance compatible

Specifications

Brand Milesight
Range 4K H.265 Pro NVR 5000 series
Inputs for IP cameras LAN port up to 8 channels
IP compatible cameras Milesight (native protocol), ONVIF S/T
Main Stream recording 8MP/6MP/5MP/4MP/3MP/1080P/UXGA/720P/D1/VGA/CIF/QCIF
Decoding capacity 3*(30fps@8MP), 4*(30fps@6MP), 4*(30fps@5MP)
6*(30fps@4MP), 8*(30fps@3MP)
8*(30fps@1080P), 8*(30fps@720P),8*(30fps@D1)
Bidirectional audio 1 RCA input / 1 RCA output / 1 output via HDMI
Video outputs 1 4K HDMI, 1 FullHD VGA
Video compression format H.265+ / H.265 / H.264+ / H.264
Display resolution HDMI: 3840x2160/30Hz, 1920x1080/60Hz, 1920x1080/50Hz,
1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz
VGA: 1920x1080/60Hz, 1920x1080/50Hz, 1280x1024/60Hz,
1280x720/60Hz, 1024x768/60Hz
Total bandwidth 160Mbps input / 160Mbps output
Simultaneous multifunction Pentaplex: live, recording, playback, backup and remote access
Alarms 4 inputs/ 1 outputs
Video Analysis Region input/output, advanced motion detection, tamper detection, line crossing, loitering,
people counting, abandoned object, removed object, object removed
Recording mode Continuous, event (motion detection, alarm, VCA, intelligent analysis)
ANPR Supported
Advanced function ANR
Internal memory 2 HDD SATA 3.5" of up to 10TB (not included)
External interface 2 x USB 2.0 / 1 x RJ45 10/100/1000Mbps
Remote access Web browser, smartphone App and PC software Milesight CMS/VMS
Operating conditions Temperature: -10℃~55℃
Humidity: 10%~90%
Power AC 100V-240V max.
Consumption ≤4W (without HDD)
Dimensions Rack-mount chassis 19" (1U standard)
380mm (W) x 317.6mm (D) x 51.8mm (H)
Weight 1.9Kg
Compliance NDAA

In the box

  • Milesight NVR Recorder
  • Mouse
  • AC/DC Adapter 12 V / 10W
  • CD with manual and software
