MS-EM500-UDL-868M
Ga direct naar de productinformatie
MS-EM500-UDL-868M
- LoRaWAN Ultrasonic Distance Sensor
- Detection of up to 8m
- Up to 10Km range with direct vision
- Configuration via NFC and APP
- Degree of Protection IP67
- Long-lasting battery
- Milesight
- LoRaWan IoT Ultrasonic Distance Sensor
- Contactless distance detection
- Suitable for use in water level monitoring, snow monitoring, grain storage, tanks, etc.
- Detection up to 8 meters
- 10 years battery life
- Frequency 868MHz
- Communication range up to 10Km with direct view
- Easy configuration via NFC and smartphone APP
- Suitable for exterior IP67
Specifications
| Technology | LoRaWAN® |
| Frequency band | 868 MHz |
| Power Output | 16dBm Max. |
| Sensitivity | -137 dBm @300bps |
| Mode | OTAA/ABP Class A |
| Range | 0.25 ~ 8 m |
| Accuracy | ± (1+0.3%*d) cm, d=distance |
| Resolution | 1 mm |
| Power supply | 1 × 19000 mAh ER34615 Li-SOCL2 |
| Battery duration | 10 years (10 minutes of interval) |
| Operating temperature | -15°C to 60°C |
| Environmental protection | IP67 |
| Dimensions | 156.1 x 71 x 69.5 mm |
In the box
- Ultrasonic sensor
- Battery
- Installation accessories
- User instructions
