MS-C8266-X4GPE
Ga direct naar de productinformatie
MS-C8266-X4GPE
- IP camera 5G AI 4X Pro Bullet Plus
- Resolution 4K | Lens 8mm~32mm
- 1/1.8" Progressive Scan CMOS
- Human- and vehicle-based AI video analysis
- IP67 | IK10 | NDAA
- Nano SIM card | 5G/4G/3G
- Milesight
- IP camera 5G AI 4X Pro Bullet Plus
- 1/1.8" Progressive Scan CMOS
- 4K (3840x2160)@25FPS
- Lens of 8mm.~32mm.
- Minimum illumination 0.009 Lux@F1.6 | 0 Lux with IR
- IR Range 180m
- Compression H.265+/H.265(HEVC)/H.264+/H.264/MJPEG
- Wireless communication 5G/4G/3G
- PoE IEEE802.3at
- Super WDR (120dB)
- Slot for MicroSD card up to 1TB
- AI video analysis in/out of area, advanced motion detection, line crossing, loitering, abandoned object, object removed
- Web, VMS/CMS, smartphone and NVR interface
- ONVIF profile G/S/T/M
- Weatherproof IP67
- Vandal proof IK10
Specifications
| Brand | Milesight |
| Range | 5G H 4X Pro Bullet Plus |
| Image sensor | 1/1.8" Progressive Scan CMOS |
| Maximum resolution | 4K (3840x2160) |
| Main Stream rate | 25fps@(3840x2160, 3072x2048, 2592x1944, 2592x1520, 2048x1536, 1920x1080, 1280x960, 1280x720, 704x576) |
| Extra Stream rate | 25fps@(704x576, 640x480, 640x360, 352x288, 320x240) |
| Rate 3rd Stream | 25fps@(1920x1080, 1280x720, 704x576, 640x480, 640x360, 320x240) |
| Compression | H.265+/H.265(HEVC)/H.264+/H.264/MJPEG |
| Bitrate | 16 Kbps ~ 16Mbps (CBR / VBR Adjustable) |
| Lens | 8mm~32mm |
| FOV | H44°~H13° / D51°~D15° / V25°~V7° (8~32mm) |
| Focus control | Auto/Manual |
| Iris Control | Auto |
| Minimum illumination | Colour: 0.009 Lux@F1.6 B/W: 0 Lux with IR ON |
| Infrared Light | 180 m |
| Day / Night | Day / Night / Auto / Customizable / Programmable |
| Advanced features | Heat Map, BLC, HLC, 2D DNR, 3D DNR, defog, AWB, IP address filtering, AGC, anti-flicker, corridor mode, deblur, watermarking |
| ROI | Up to 8 Areas |
| Intelligent Analysis | Advanced motion detection, line crossing, loitering detection, region entry, region exit, object left, object removed |
| Face and attribute detection | Detects and captures faces, takes images in real time; Attributes include age, gender, glasses, mask and cap; Supports face privacy mode, faces detected in the face detection area are masked automatically. |
| Object counting and reporting | Counts the number of objects crossing a line, optionally humans and vehicles. Supports regional people counting up to 4 detection areas. |
| Trigger Event | Motion detection, Exceptions, Alarm input, audio alarm, etc. |
| Event Action | Upload Image to FTP, SMTP, MicroSD card, enable alarm output, SIP call, HTTP notification |
| Communication Interface | Ethernet Port 1*RJ45 10M/100M |
| Internal memory | Supports local storage microSD/SDHC/SDXC card up to 1TB |
| Audio Compression | G.711/AAC/G.722/G.726 |
| Audio Bit Rate | 16~256Kbps |
| SIP/VoIP | Yes. Voice and video over IP |
| Remote access | Web browser, smartphone App and software Milesight Central Management System, Milesight VMS Enterprise |
| Wireless communication | 5G/4G/3G |
| SIM card | Nano SIM |
| Interoperability | ONVIF (Profile G/S/T/M) |
| Power | PoE (802.3at) / DC 12V±10% |
| Consumption | Max.: 13.2W (DC 12V), 16W (PoE) |
| Degree of protection | Weatherproof IP67, IK10 |
| Download protection | 4KV |
| Temp. operation | -40ºC~+60ºC |
| Operating humidity | 0~95% (without condensation) |
| Dimensions | 320mmX134mmX126mm 320mmX134mmX292mm (with antennas 5G)) |
| Weight | 1608g |
| Certifications | EMC: CE-EMC (EN 55032, EN 55035), FCC (PART 15B)) Security: CE-LVD (EN IEC 62368-1)) Environment: CE-ROHS (Directive (EU) 2015/863 modifying 2011/65/EU) |
In the box
- IP camera 5G AI 4X Pro Bullet Plus
- Installation material
- Template for easy installation
