MS-C4573-PD
Ga direct naar de productinformatie
MS-C4573-PD
- IP Mini Dome Camera
- 4Mpx | 1/2.8" Progressive Scan CMOS | Lens 2.8
- Built-in microphone , Alarm , Audio
- IR 30m | 120dB Super WDR
- Human- and vehicle-based AI video analysis
- IP67 | IK10 | MicroSD
- Milesight
- IP Mini Dome Camera
- 1/2.8" Progressive Scan CMOS
- 4 Megapixel (2688x1520)
- Lens of 2.8mm
- Minimum illumination 0.005Lux@F1.6 (color) | 0 Lux with IR
- IR Range 30 m
- Compression H.265+/H.265(HEVC)/H.264+/H.264/MJPEG
- Audio
- Alarms
- Integrated microphone
- PoE IEEE802.3af
- Super WDR (120dB)
- Slot for MicroSD/SDHC/SDXC card up to 1TB
- Video analysis with line crossover, input region, marauding
- Counting people with reports
- WEB, CMS, Smartphone and NVR interface
- ONVIF, API support
- Weatherproof IP67
- Anti-vandal K10
Specifications
| Brand | Milesight |
| Image sensor | 1/2.8" Progressive Scan CMOS |
| Maximum resolution | 4 Megapixel (2688x1520) |
| Lens | 2.8mm |
| FOV | 106º(H), 58º(V), 124º(D) |
| Main Stream rate | 60Hz: 30fps@(2688x1520, 2304x1296, 1920x1080, 1280x720) 50Hz: 25fps@(2688x1520, 2304x1296, 1920x1080, 1280x720) |
| Extra Stream rate | 60Hz: 30fps@(1280x720, 704x576, 640x480) 50Hz: 25fps@(1280x720, 704x576, 640x48 |
| Rate 3rd Stream | 60Hz: 30fps@(1280x720, 704x576, 640x480) 50Hz: 25fps@(1280x720, 704x576, 640x480) |
| Compression | H.265+/H.265(HEVC)/H.264+/H.264/MJPEG |
| Bitrate | 16 Kbps ~ 16 Mbps (CBR / VBR Adjustable) |
| Minimum illumination | Colour: 0.005Lux@F1.6 B/W: 0 Lux with IR ON |
| IR range | 30 m |
| Day / Night | Day / Night / Auto / Customizable / Programmable |
| Image improvements | BLC, HLC, 2D DNR, 3D DNR, Defog Function, AWB, EIS, IP Address Filtering, AGC, Anti Flicker, Corridor Mode, Watermarking |
| WDR | 120dB |
| ROI | Up to 8 Areas |
| Intelligent Analysis | Motion Detection, Line Crossing, Loitering Detection, Region Entry, Region Exit, Object Left, Object Removed |
| People Counting & Reporting | People counting at entrances and exits. Supports up to 4 people counting regions |
| Trigger Event | Motion Detection, Exceptions, Alarm Inputs |
| Event Action | Upload Image to FTP, SMTP, MicroSD Card, Enable Alarm Output, SIP Phone, HTTP Notification |
| Communication Interface | Ethernet Port 1*RJ45 10M/100M |
| Internal memory | MicroSD card, Max 1 TB |
| Alarms | 1/1 |
| Audio | Microphone / 1 Input / 1 Output |
| Audio Compression | G.711/AAC/G.722/G.726 |
| Two-way Audio | Support |
| Audio Bit Rate | 16~256Kbps |
| SIP/VoIP | Support. Voice and Video over IP |
| Remote access | Web Browser, Smartphone App and Milesight Central Management System Software |
| Interoperability | ONVIF (G/S/T Profile), API |
| Power | DC 12 V / MAX 6W(con IR ON), PoE IEEE802.3af |
| Degree of protection | Waterproof IP67, Anti-vandal IK10 |
| Temp. operation | -40º C ~ +60º C |
| Dimensions | 65 (H), 110.8 (W), 118.5 (D) mm |
| Weight | 500 g |
In the box
- IP Mini Dome Camera
- Installation material
- Template for easy installation
