MS-C2972-RFLPE
- IP LPR Camera for Incoming and Outgoing
- Resolution 2Mpx@60fps | IR 20m
- Supervision up to 2 lanes <30Km/h
- 2.7~13.5mm motorised auto-focus lens
- Recognition of brand, type, color and address
- Micro SD Card | Relay output | IP67
- Milesight
- IP License Plate Camera for Entry and Exit
- 1/2.8" Progressive Scan CMOS
- 2 Megapixel (1920x1080)@60FPS
- Motorised, varifocal, lens 2.7~13.5mm Autofocus
- 0 Lux
- IR Range 20 m
- Number plate reading up to 30km/h
- Monitors upto 2 lane(s)
- Compression H.265+
- WDR (140dB)
- RJ-45 10/100Mbps
- Audio
- Alarms
- Brand, color, type, address recognition
- Evidence camera linkage
- License plate search
- Recording and storage of license plates on MicroSD card
- PoE IEEE802.3af
- Weatherproof IP67
- Vandal proof IK10
- ONVIF Compatible
Specifications
| Brand | MILESIGHT |
| Image sensor | 1/2.8" Progressive Scan CMOS |
| Maximum resolution | 2 Megapixel (1920x1080) |
| Main Stream rate | 60fps@(1920x1080, 1280x960, 1280x720, 704x576) |
| Extra Stream rate | 60fps@(704x576, 640x480, 640x360, 352x288, 320x240, 320x192, 320x180) |
| Rate 3er Stream | 30fps@(1920x1080, 1280x720, 704x576, 640x480, 640x360, 320x240) |
| Compression | H.265+ / H265 /H.264+ / H264 / MJPEG |
| Bitrate | 16 Kbps ~ 16 Mbps |
| Lens | 2.7~13.5mm Motorised auto-focus |
| FOV | H61°~H5°/D69°~D5°/V36°~V2° |
| Minimum illumination | Colour: 0.005Lux@F1.4 B/W: 0lux with infrared |
| Lighting | IR up to 20m |
| Image improvements | WDR (140 dB), BLC, 3D-NR, AWB, Privacy Masking, ROI |
| LPR | Input and output application Supervision up to 2 lanes Maximum speed up to 30Km/h |
| Intelligent traffic detection | Recognition of license plate, license plate type, vehicle make, vehicle color, vehicle type and vehicle address |
| Alarm warnings | Capable of recognizing license plates in a black or white list (max. 20000 license plates) to activate different actions |
| Day / Night | Removable mechanical ICR filter |
| Internal memory | MicroSD card, Max 1TB (needed to use LPR function) |
| Alarms | 1/1 |
| Audio | 1/1 |
| Communication Interface | Ethernet 10/100M BaseT SIP / VoIP |
| Remote access | Web Browser, Smartphone App and Milesight Central Management System Software |
| Interoperability | API, MQTT, HTTP, TCP, ONVIF (Profiles G, M, S and T) |
| Power | DC 12 V / MAX 10W, PoE IEEE802.3af |
| Degree of protection | Waterproof IP67 / Anti-vandal IK10 |
| Temp. operation | -30º C ~ +60º C |
| Dimensions | 134 (W) X 126 (H) X 285 (D) mm |
| Weight | 1080 g |
In the box
- MILESIGHT LPR IP Dome Camera
- Installation material
- CD with software and instructions
- Template for easy installation
- Junction box
