iDS-7608NXI-P2
- Hikvision NVR recorder 8 IP CH PRO range
- Bandwidth 128 Mbps
- Maximum resolution 32 Mpx
- AcuSearch | AcuSense | Facial recognition
- AcuSeek, text-based search
- Audio | Alarms | 2 HDD
- Hikvision
- PRO Range
- NVR for IP cameras
- 8 CH
- Supported incoming bandwidth 128 Mbps
- Maximum resolution 32 Mpx
- Compression H.265+/H.265/H.264+/H.264
- Outputs 4K HDMI & VGA
- Artificial intelligence based on large-scale algorithm Guanlan
- Motion detection 2.0 all channels
- AcuSense, false alarm filter for vehicles and persons (in line crossing and area intrusion)
- AcuSeek, text-based search in natural language
- AcuSearch, target image search on all channels
- Facial recognition
- Alarms
- Audio
- IP Dual Stream Access
- Mouse
- Space for 2 HDD
- WEB, CMS and Smartphone interface
- ONVIF Compatible
Specifications
| Brand | Hikvision |
| Range | DeepMind PRO |
| Inputs for IP cameras | 8 channels |
| IP compatible cameras | HIKVISION (native protocol), ONVIF |
| Video outputs | 1xHDMI 8K, 1xVGA independent |
| Video compression format | H.265+ / H.265 / H.264+ / H.264 |
| Display resolution | HDMI: 8K (7680×4320)/30Hz，4K (3840×2160)/60Hz，4K (3840×2160）/30Hz，2K (2560×1440)/60Hz, 1080P (1920×1080)/60Hz VGA: 1080P (1920 × 1080)/60 Hz * HDMI and VGA are independent |
| Total bandwidth | 128 Mbps downstream / 256 Mbps upstream |
| Stream Type | Video / Video + Audio |
| Main Stream recording | 32 MP / 24 MP / 12 MP / 8 MP / 6 MP / 5 MP / 4 MP / 3 MP / 1080p / UXGA / 720p / VGA / 4CIF / DCIF / 2CIF / CIF / QCIF |
| Decoding capacity | 2-ch@32 MP (30 fps)/2-ch@24 MP (30 fps)/4-ch@16 MP (30 fps)/8-ch@8 MP (30 fps) |
| Intelligent functions | For NVR: Facial recognition, Perimeter protection, AcuSearch, AcuSeek With cameras with intelligent functions: Facial recognition, Perimeter protection, AcuSearch, Motion detection 2.0, ANPR, People counting, VCA |
| Perimeter Protection | For NVR: Available in 8-ch 2 MP or 8ch-4MP or 4-ch 8MP With AcuSense cameras: Available in all channels. |
| Facial recognition | Face comparison, face capture, face search. Storage in up to 32 libraries with up to 100.000 faces in total Face detection and analysis tools up to 8CH with 2~4 Mpx. or in up to 4 channels with 8 Mpx. Face comparison in up to 16 CH. |
| AcuSearch | Video search from target images. Several targets can be detected at the same time in the image and the target to be searched for can be selected. With AcuSearch technology cameras: available for all channels |
| AcuSeek | Searching through large amounts of video recordings using natural language text descriptions. If the cameras support AcuSense technology and have AcuSearch enabled, the NVR supports AcuSeek on all channels and is capable of modeling 50.000 targets per day. |
| ANPR | Supports license plate search on all channels with ANPR-enabled cameras |
| Alarms | 4 In / 1 Out |
| Audio | 1 input / 1 output |
| Bidirectional audio | 1 RCA output |
| Audio Compression | G.711ulaw/G.711alaw/G.722/G.726/AAC/MP2L2 |
| Recording method | Manual, programmed, motion detection |
| External Backup | USB memory / HDD USB / CD-RW USB / DVR-RW USB |
| Remote access | Web Browser, Hik-Connect Smartphone App, PC Software iVMS-4200 and Hik-Central |
| Remote connections | 128 |
| Internal memory | 2 SATA HDD 3.5" of up to 20 TB (not included) |
| Communication | 1 x USB 2.0 front, 1 x USB 3.0 back 2, RJ-45 10/100/1000 Mbps |
| Power | DC 12 V, 5 A, ≤ 50 W (no HDD) |
| Operating temperature | -10ºC ~ 55ºC (10%-90% Humidity) |
| Dimensions | 46 (H) x 444 (W) x 415 (D) mm |
| Weight | ≤ 4 Kg (without HDD) |
In the box
- Hikvision NVR recorder
- Mouse
- Ethernet Cable
- Instructions Manual
- Hard disk connection wiring
- Power supply
