IB-TE-MP-65E1-V3
Ga direct naar de productinformatie
IB-TE-MP-65E1-V3
- Interactive monitor 65''
- Resolution 4K
- Android 14
- 8 GB RAM and 128 GB ROM
- Integrated microphones
An interactive display is a digital device with touch technology that allows direct interaction with its own software or with a PC (connected as a peripheral or through the use of an OPS), fostering collaboration, productivity and active user participation. These displays integrate advanced functionalities such as touch typing, real-time annotation tools and multi-device connectivity, making them a versatile and adaptable solution for a variety of needs.
They are used in different areas of the public and private sector, such as in education for dynamic classes, in companies for presentations and meetings, or in design for creative work, among others, which makes them a key tool for digital transformation.
- Interactive monitor 65"
- Resolution 4K
- Android 14
- Brightness 500 cd/m2
- Processor 2x A76 + 2x A55
- 8 GB RAM
- 128 GB ROM
- Integrated microphones
Specifications
General |
|
| Brand | IBOARD |
| Type | Interactive monitor |
| Size | 65'' |
Panel | |
| Resolution | 3840x2160 |
| Refresh rate | 60 Hz |
| Aspect ratio | 16:9 |
| Brightness | 500 cd/m2 |
| Contrast | 1200:1 |
| Response time | 8 ms |
| Backlight | D-LED |
| Viewing angle (horizontal / vertical) | 178º / 178º |
Tactility | |
| Touch technology | Infrared frame |
| Simultaneous touches | ≤ 20 (Android) ≤ 50 (Windows) |
| Tactile precision | Opaque objects of <2 mm |
Conectividad | |
| Entradas frontales | HDMI 2.0 x1 USB-C (Táctil, datos, audio, video y 15W de carga) x1 USB 3.0 x3 USB-B (Táctil) x1 |
| Entradas traseras | HDMI 2.0 x2 VGA & AUDIO x1 DP x1 USB-C (Táctil, datos, audio y video) x1 UBS 3.0 x3 Touch-USB x1 RS232 x1 RJ45 x1 MIC x1 Ranura para tarjeta TF x1 Ranura para OPS x1 |
| Salidas | HDMI x1 SPDIF (Óptico) x1 Cascos x1 RJ45 x1 |
| Bluetooth | 5.2 |
| NFC | Compatible con tarjetas NFC iBoard - Encendido/apagado de la pantalla interactiva - Cambio de usuario |
| Wi-Fi | WIFI 6, 5G/2.4G |
| Red | 10 / 100 / 1000 Mbps |
Sistema | |
| Sistema operativo | Android 14.0 |
| Procesador | 2x A76 (1,9 GHz) + 2x A55 (1,9 GHz) |
| GPU | MaliG57 |
| RAM | 8 GB |
| ROM | 128 GB |
Audio y video | |
| Altavoces | 2x20 W + subwoofer 20 W |
| Micrófonos | Array de 8 micrófonos |
| Rosca para acoplar cámara | 1/4 hembra |
Aspecto físico | |
| Sensor de brillo | Sí |
| Cristal antirreflejo | Sí |
| Grosor del cristal | 4 mm |
| Botones frontales | Encendido/Apagado (Power) Fuente (Source) Menú (Menu) Bajar volumen (Vol - ) Subir volumen (Vol +) Inicio (Home) Introducir (Enter) Apagado del panel (ES) |
| Dimensiones | 1485 (An) x 905 (Al) x 85 (Fo) mm |
| VESA | 500x400 mm |
| Peso | 37 Kg |
Enegía | |
| Alimentación | AC 100 V ~ 240 V, 50/60 Hz |
| Consumo sin OPS | <1W (Standby) < 250W (Potencia nominal) |
In the box
- Monitor interactivo
- Cable de alimentación
- Cable HDMI
- Cable USB-B a USB-A
- 2x Lápiz pasivo
- 2x Tarjeta NFC
- Mando a distancia
- Soporte fijo a pared
