HDMI-ONVIF
- Video Encoder
- Resolution up to 1920x1080p
- Encoding H.264
- Video Encoder
- HDMI to ONVIF signal converter
- Resolution up to 1920x1080p
- Format H.264
- Compatible with various live streaming platforms
- Compatible with video surveillance devices over ONVIF
Specifications
| Encoder | HDMI-ONVIF |
| Resolution | 1920x1080pHz |
| Video input | 1 x HDMI |
| Audio input | 1 x embedded audio from HDMI port |
| Type of coding | H.264 |
| Coding resolution | 1920x1080/ 1680x1056/1280x720/1024x576/850x480/720x576/720x540/ 720x480/ 720x404/704x576/640x480/640x360/608x448/544x480/ 480x480/ 480x384/480x360/480x332/480x272/480x270/400x320/ 400x224/ 352x480/352x352/352x228/320x256/320x240/320x180/ 240x180/ 176x144/lo same as input resolution |
| Compatible with | RTMP/ RTSP/ HTTP FLV/ HLS/ UDP Multicast/RTB Multicast |
| Operating temperature | -20 ℃ - 60 ℃ |
| Dimensions / Weight | 104 × 104 × 27 mm / 560g |
| Power | DC 12V / 2A |
In the box
- Video Encoder
- DC power supply 12V / 2A
- HDMI cable
