DS-E04HQHI-B
Ga direct naar de productinformatie
DS-E04HQHI-B
- Hikvision DVR 5n1
- 4 CH HDTVI / HDCVI / AHD / CVBS
- 1 channel IP 6 MPx
- Maximum input resolution 5 MPx
- integrated eSSD 512 GB Low consumption
- Audio over coaxial | Motion Detection 2.0
- Hikvision
- DVR 5n1
- 4 CH vídeo HDTVI/HDCVI/AHD/CVBS / 1 CH IP
- /H.265 Pro/H.265
- Maximum input resolution 5MPxLite@20fps
- Audio over coaxial
- Motion detection 2.0
- Full HD HDMI and VGA Output
- eSSD included 512 GB
- Very light and small size device
- Low consumption
Specifications
| Brand | HIKVISION |
| Range | Value |
| Video format | HDTVI / HDCVI / AHD / CVBS / IP |
| Video inputs | 4 Channels BNC (HDTVI / HDCVI / AHD / CVBS) |
| Hybrid configuration | 1CH Additional IP up to 6 MPx |
| Available bandwidth | 72 Mbps |
| Video outputs | 1 HDMI Full HD and 1 VGA, simultaneous; |
| Display resolution | HDMI: 1920x1080, 1280x1024, 1280x720 / 60 Hz VGA: 1920x1080, 1280x1024, 1280x720 / 60 Hz |
| Audio inputs | Audio over coaxial on all BNC input channels |
| Audio outputs | Audio output via HDMI output |
| Audio Bit Rate | 64 Kbps |
| Audio compression | G.711u |
| Video compression | Analog channels: H.265 Pro / H.265 IP channels: H.265 Pro / H.265 |
| Recording resolution | 4MPx Lite/ 1080p/ 1080p Lite/ 720p/ WD1/ 4CIF/ CIF |
| Input resolution | HDTVI: 5MPx (20 fps), 3K (20 fps), 4MPx (25~30 fps), 1080p (25~30 fps), 720p (25~30 fps) HDCVI: 4MPx (25~30 fps), 1080p (25~30 fps), 720p (25~30 fps) AHD: 4MPx (25~30 fps), 1080p (25~30 fps), 720p (25~30 fps) CVBS: PAL/NTSC |
| Main Stream coding | When 1080p Lite mode is not enabled: For the stream of 4 MPx: 4MPx Lite (15 fps), 1080p/720p/WD1/4CIF (25 fps (P), 30 fps (N)) For the 1080p stream: 1080p/720p (15 fps), WD1/4CIF (25 fps (P), 30 fps (N)) For the 720p stream: 720p/WD1/4CIF(25 fps (P), 30 fps (N)) When 1080p Lite mode is enabled: 4MPx Lite (15 fps), 1080p Lite/720p Lite/WD1/4CIF (25 fps (P), 30 fps (N)) |
| Extra Stream coding | WD1/4CIF (12 fps), CIF (25 fps (P), 30 fps (N)) |
| Video Bit Rate | Video bitrate adaptable according to scene type |
| Simultaneous multifunction | Pentaplex: Live, Recording, Playback, Backup and Remote Access |
| Alarms | Does not have |
| Motion Detection | Motion detection 2.0 with human and vehicle classification applied in motion detection. Available on all analog channels. |
| Recording method | Manual, programmed, motion detection |
| Internal memory | 1 eSSD included - 512 GB (480 GB available) |
| Communication | 2 x USB 2.0 (rear side) / 1 x RJ45 (Ethernet) |
| Remote connections | 32 |
| Remote access | Web Browser, Hik-Connect Smartphone App, PC Software iVMS-4200 and Hik-Central |
| Power | DC 12 V, 1 A, ≤ 5.4 W (with eSSD) |
| Operating temperature | -10° ~ +45° C |
| Dimensions / Weight | 46 (H) mm x 151 (W) mm x 121 (D) mm / ≤ 0.5 Kg (with eSSD) |
In the box
- 5in1 Hikvision recorder
- Mouse
- Power adapter AC/DC 12 V
- CD with manual and software
