Name: AE-VC1B1I-ISF(RJ45)(6mm)
Brand: HIKVISION SOLUTIONS
SKU: AE-VC1B1I-ISF(RJ45)(6mm)
Price: 684.95 EUR
Availability: OutOfStock

AE-VC1B1I-ISF(RJ45)(6mm)

6 driving behavior analytics
High-performance global shutter 1/4"
Integrated speaker
Voltage range 9-36 V DC
IR of 940nm

DSM camera for driver monitoring. It features built-in video analytics to detect fatigue, the wearing of sunglasses, failure to wear a seatbelt, yawning, and other events. Built-in speaker for driver alerts and an 940-nanometer IR light that does not interfere with vision while driving.

6 driving behavior analytics
High-performance global shutter 1/4" for excellent image quality
Built-in speaker for alerts to the driver in case of distraction
Extended power supply range of 9-36V DC for various types of vehicles
IR from 940nm that does not obstruct the driver's visibility while driving

Specifications

Camera Specifications
Minimum illumination	0,00 Lux@(F1.2, AGC activado)
Image sensor	High-speed global shutter sensor with 1/4"
Day/night switching	Night mode only
Adjustment angle	Left and right: -43°~43°; Front and back: -43°~67°; Horizontal: 0°~360°
Lens
Focal length and field of view	6 mm: horizontal field of view 54°, vertical field of view 31°, diagonal field of view 62°
Lens Assembly	M8
Lens type	Fixed
Illuminator
Type of light	Low-visibility IR light (no red glow)
Wavelength	940nm
IR range	Up to 10 meters
Video
Maximum resolution	1280 × 720
Main Stream	50 Hz: 25 fps (1280 × 720) 60 Hz: 30 fps (1280 × 720)
Secondary Stream	50 Hz: 25 fps (704×576, 640×480, 352×288, 320×240) 60 Hz: 30 fps (704×576, 640×480, 352×288, 320×240)
Tertiary stream	50 Hz: 25 fps (1280 × 720) 60 Hz: 30 fps (1280 × 720)
Video compression	Main Stream: H.264 , H.265 Secondary Stream: H.264 , H.265 , MJPEG Tertiary stream: H.264 , H.265
Bitrate	Main Stream: from 256 kbps to 8192 kbps Secondary Stream: from 256 kbps to 4096 kbps Tertiary stream: from 256 kbps to 4096 kbps
Type of H.264	BaseLine Profile / Main Profile / High Profile
Type of H.265	Main Profile
Control Bitrate	CBR/VBR (constant/variable)
Audio
Audio Compression	G711U，G711A，G726，AAC，G722，PCM
Audio bitrate	64Kbps(G.711U)/64Kbps(G.711A)/16Kbps(G.726)/16Kbps(AAC)
Network
Protocols	TCP/IP, ICMP, HTTP, HTTPS, DHCP, DNS, RTP, RTSP, NTP
Simultaneous video	Up to 8 channels
API	HIK SDK, ONVIF (S/G/T Profile), ISAPI
User Management	Up to 16 users, 3 levels: Administrator, Operator, and User.
Web browser	IE8+, Chrome45+, Edge41+, Firefox45+
Day/night switching	Night mode only
Interface
Ethernet	-RJ45: Cable RJ45+DC
Audio	Audio input: Integrated microphone Audio output: Integrated speaker
Memory card	Built-in Micro TF slot, up to 256 GB (not available on the base model). (Please note the capacity of the Micro TF card when placing your order).
Events
Video analytics	Distraction detection, driver fatigue detection (eyes closed), detection of sunglasses using infrared technology that obstructs vision. Tamper detection, seat belt unfastened detection, driver fatigue detection (yawning). Driver exception detection, tamper detection.
General
Dimensions	91.5 mm × 91.5 mm × 107.9 mm (3.6" × 3.6" × 4.3")
Consumption	DC: 0.19-0.78 A, 7 W MAX
Material	Metallic
Weight	Approx. 405 g (0,9 pounds)
Start-up and operating conditions	-30 °C to 75 °C ((-22 °F to 167 °F), humidity of 90 % or less (no condensation)
Power	DC 9-36 V
Cable length	50 cm
Regulations
EMC	FCC: FCC-SDoC (ANSI C63.4, FCC Part 15 Subpart B) CEM CE: CE-EMC (EN 55024):2010 +A1:2015,EN 55032:2015,EN 61000-3-2:2014,EN 61000-3-3:2013
Security	CE: CE-LVD(EN 60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013)
Environment	CE: CE-RoHS (RoHS Directive 2011/65/UE+2015/863) Scope of SVHCs: Regulation (EC) No. 1907/2006
Automotive and Rail	EN50155: EN 50155-2007,EN 50155-2017 EN45545: (EN 45545-2:2013+A1:2015); E-MARK (ECE R10)
