ADV-20-SGWE
Ga direct naar de productinformatie
ADV-20-SGWE
- Wireless Expander Module
- Compatible with the ARGUS wireless range
- Allows you to expand the wireless coverage range
- Power supply from 9 to 30 VDC
- Advanced
- Wireless amplifier
- Up to 7 expanders used with each ADV-20-VW2W100
- Easy installation, externally motorized
- Bidirectional communications with all devices
Specifications
| Brand | Advanced |
| Power | 9~30 VDC |
| Communication distance | Up to 200 meters |
| Frequency | 868.15 MHz –869.85 Mh FSK |
| Frequency channels | 7 |
| Emission power | 5 dBm (3mW) |
| Operating temperature range | -30ºC ~ +50ºC |
| Dimensions | 120 x 160 x 51 mm (HxWxD) / Antenna 74mm |
| Weight | 330g |
| Degree of protection | IP51C |
| Programming software | "Wirelex-Fire" version 5.0 or higher |
In the box
- Wireless expander
