AC-12DC2A-BAT
- Power supply for access control
- Configurable NO/NC
- DC output 13.5V / 2A
- Metal box with lock
- Lithium auxiliary battery 12V / 7Ah included
- Surface mounting
- Power supply
- Specific for access control: power device and lock
- Metal box with lock
- AC input 220V
- DC output 13.5V / 2A
- 12V / 7Ah lithium auxiliary battery included
- Lock control NC/NO
- Built-in anti-lock inductor circuit
- Built-in adjustable unlocking potentiometer
Specifications
| Model | AC-12DC2A-BAT |
| Power supply input | AC 220 V |
| Power supply output | 13.5 V / 2 A |
| Lock type | Configurable NO/NC |
| Lock release | Adjustable between 0 and 10 seconds |
| Backup battery | Lithium 12 V / 7 Ah (included) |
| Temp. operating | -20 ºC ~ +60 ºC |
| Dimensions | 194 (H) x 94 (W) x 44 (D) mm |
| Weight | 2 kg |
In the box
- Power supply
- User manual
- Security key
- Backup battery
