AC-12DC2A
Ga direct naar de productinformatie
AC-12DC2A
- Power supply for access control
- Configurable NO/NC
- DC output 12.8V / 1.8A
- Metal box with lock
- Surface mounting
- Power supply
- Specific for access control: power device and lock
- Metal box
- AC input 220V
- DC output 12.8V / 1.8A
- Lock control NC/NO
- Built-in anti-lock inductor circuit
- Built-in adjustable unlocking potentiometer
Specifications
| Model | AC-12DC2A |
| Power supply input | AC 220 V |
| Power supply output | 12.8 V / 1.8 A |
| Lock type | Configurable NO/NC |
| Lock release | Adjustable between 0 and 10 seconds |
| Backup battery | Not suitable for battery backup |
| Temp. operating | -20 ºC ~ +60 ºC |
| Dimensions | 185 (H) x 78 (W) x 64 (D) mm |
| Weight | 1.5 kg |
In the box
- Power supply
- Features manual
- Security key
